Belden 5300FE Security & Sound, 2 Conductor 18 AWG, BC, Shielded, CMR Belden 2 Core Shielded 18 Awg

Name: Belden 5300FE Security &amp; Sound, 2 Conductor 18 AWG, BC, Shielded, CMR Belden 2 Core Shielded 18 Awg
SKU: BELDEN-5300UE-1
Price: 140000 PKR
Availability: InStock

SKU: BELDEN-5300UE-1

Security & Commercial Audio Cable, Riser-CMR, 2-18 AWG stranded bare copper conductors with polypropylene insulation, Beldfoil® shield and PVC jacket with ripcord

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%

Sale_coupon_15

₨ 140,0001

Compare

Add to wishlist

12 People watching this product now!

Pick up from the Woodmart Store

To pick up today

Free

Courier delivery

Our courier will deliver to the specified address

2-3 Days

Free

DHL Courier delivery

DHL courier will deliver to the specified address

2-3 Days

Free

Warranty 1 year

More details

Free 30-Day returns

More details

Payment Methods:

Description

Best Price in Pakistan Belden. Belden Best Price in Pakistan, Belden in wholesale rate available.

Belden 5300FE Available in Pakistan. Belden 5300FE Available in Karachi. Belden 5300FE Available in Lahore. Belden 5300FE Available in Islamabad. Belden 5300FE Available in Rawalpindi. Belden 5300FE Available in Multan. Belden 5300FE Available in Hyderabad.

Specifications

Suitable Applications	Intercom/PA Systems, Sound/Audio Systems

Element	No. of Elements	Size	Stranding	Material
Conductor(s)	2	18 AWG	7×26	BC – Bare Copper

Element	Material	Nom. Thickness	Nom. Insulation Diameter	Color Code
Conductor(s)	PO – Polyolefin	0.009 in (0.23 mm)	0.062 in (1.6 mm)	Black, Red

Shield Type	Material	Coverage	Drainwire Type
Tape	Bi-Laminate (Alum+Poly)	100%	24 AWG (7×32) TC

Material	Nom. Thickness	Nom. Diameter	Ripcord
PVC – Polyvinyl Chloride	0.017 in (0.43 mm)	0.162 in (4.11 mm)	Yes

Overall Cable Diameter (Nominal)	0.162 in (4.11 mm)

Element	Nom. Conductor DCR	Nom. Capacitance Cond-to-Cond	Nom. Capacitance Cond-to-Other (Conds + Shield)	Max. Current
Conductor(s)	6.5 Ohm/1000ft	53 pF/ft (170 pF/m)	95.5 pF/ft (313 pF/m)	5 Amps per conductor @ 25°C

UL Voltage Rating
300 V (CMR)

UL Temperature	Operating
75°C	-20°C to +75°C

Stationary Min.	Installation Min.
1.6 in (41 mm)	1.6 in (41 mm)

Max. Pull Tension	58 lbs (26 kg)
Bulk Cable Weight	18 lbs/1000ft

Environmental Suitability	Indoor – Riser, Indoor
Flammability / Reaction to Fire	UL 1666 Riser, FT4, IEC 60332-1-2
CPR Compliance	CPR Euroclass: Eca
NEC / UL Compliance	Article 800, CMR
CEC / C(UL) Compliance	CMG
European Directive Compliance	EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
UK Regulation Compliance	UKCA Mark
APAC Compliance	China RoHS II (GB/T 26572-2011)
Plenum Number	6300FE
